PZ73

Door switch and hook lock positive contact

The door contact PZ73 is a safety switch with forced actuation and is used to control the close position of lift doors resp. as switch for locking mechanism at automatic doors.

PZ73

PZ73

PZ73

PZ73

Features

  • safety switch with positive contact
  • use for monitoring the closure position of lift doors resp. as switch for locking mechanism of automatic doors
  • enclosure made of thermoplastic, self-extinguishing
  • actuation direction can be changed
  • high contact safety by self-cleaning
  • quiet functioning
  • mounting brackets made of metal for secure fixation
  • as option with UL-marking

Order information codes

Technical data

norms EN 81-20, EN 81-50, EN 60947-5-1
switching capacity Ui = 500 V Ith = 10 A Uimp = 4 kV
AC-15: Ue = 230 V Ie = 2 A DC-13: Ue = 200 V Ie = 2 A
short-circuit capacity T10 A F 16 A
contact material fine silver
actuation force 1.6 N
connection by screw terminal max. 2.5 mm²
level of protection IP20
ambient air temperature -30 °C up to +80 °C
installation position any
weight 42 g
