BS-V

Latch plate with height adjustment

The latch plate BS-V with height adjustment allows the adaptation to different material thicknesses of door leaves or a readjustment when the door is lowered. This version is particularly suitable for retrofitting into doors as only a round hole is needed in the door leaf.

BS-V

BS-V

BS-V

BS-V

Features

  • latch plate for
    – holding the latch bolt of a door interlock
    – actuation of the faulty closure device
    – mounting in the door leaf
  • center part height adjustable, allows compensation of different sheet thicknesses and
    readjustment at misalignment of the door
  • anti-rotation protection against autonomous readjustment of the center part has to be ensured by loctite or alike
  • compatible with basic type BE (directly interchangeable)
  • sliding nuts for alignment of the latch plate
  • adjusting ring included in the scope of delivery

Order information codes

Technical data

enclosure zinc diecast, stainless steel
customary position any
ambient air temperature -30 °C up to +80 °C
weight 70 g
